变速箱传动比:
| Number of stages |
1 |
2 |
3 |
4 |
5 |
| Reduction Ratio i |
4、4.75 |
16、22.5 |
64、79、107 |
256、361、509 |
1024、2418 |
| Gearbox Length L (mm) |
15.2 |
19.8 |
24.4 |
29 |
33.6 |
| Breaking Torque(kgf.cm) |
2 |
3 |
4 |
5 |
5 |
| Gearbox Efficiency |
90% |
81% |
73% |
65% |
59% |
|
|
|
|
|
|
直流电机数据:
备注：以上直流电机数据用于根据给定公式定制直流齿轮电机.
| DC Motor Model |
Rated |
No Load |
Max Efficiency Load |
Stall |
| Volt. |
Current |
Speed |
Current |
Speed |
Torque |
P.out |
Torque |
Current |
| V |
mA |
r/min |
mA |
r/min |
gf.cm |
W |
gf.cm |
mA |
| DM-180-006-6000 |
6 |
≤65 |
6000 |
≤260 |
5100 |
15 |
0.8 |
≥55 |
≥1150 |
| DM-180-012-6000 |
12 |
≤27 |
6000 |
≤150 |
5100 |
15 |
0.8 |
≥55 |
≥430 |
| DM-180-012-9000 |
12 |
≤80 |
9000 |
≤260 |
7000 |
20 |
1.4 |
≥80 |
≥1000 |
| DM-180-024-9000 |
24 |
≤50 |
9000 |
≤ 150 |
7800 |
20 |
1.6 |
≥80 |
≥550 |
|
|
|
|
|
|
|
|
|
|
齿轮电机数据:
备注：以上图表中的数据仅供参考。如需其他配置，可根据以下公式计算，或直接联系我们.
| DC Gear Motor Model |
Rated voltage |
No Load |
Max Efficiency Load |
Stall |
| Current |
Speed |
Current |
Speed |
Torque |
P.out |
Torque |
Current |
| V |
A |
r/min |
A |
r/min |
kgf.cm |
W |
kgf.cm |
A |
| DM-22PM18000675.4-107K |
6 |
0.16 |
75.4 |
0.54 |
58.4 |
1.58 |
0.95 |
7.01 |
1.82 |
| DM-22PM18000631.5-256K |
6 |
0.16 |
31.5 |
0.58 |
24.6 |
3.26 |
0.83 |
15.04 |
2.09 |
| DM-22PM180009105.2-107K |
9 |
0.17 |
105.2 |
0.65 |
81.3 |
2.26 |
1.89 |
9.95 |
2.27 |
| DM-22PM180012077-107K |
12 |
0.11 |
77 |
0.151 |
69.7 |
9.72 |
0.710 |
89.46 |
1.225 |
| DM-22PM18002474-107K |
24 |
0.09 |
74 |
0.106 |
48.9 |
1.58 |
0.808 |
5.921 |
0.293 |
| DM-22PM18001217.7-509K |
12 |
0.18 |
17.7 |
0.288 |
13.5 |
7.7 |
1.088 |
36.97 |
1.091 |
| DM-22PM180012019-428K |
12 |
0.15 |
19 |
0.38 |
12 |
10 |
1.2 |
35.8 |
1.02 |
| DM-22PM180012016-361K |
12 |
0.04 |
16 |
0.13 |
12 |
3.9 |
0.47 |
15.75 |
0.41 |
| DM-22PM180006209-43K |
6 |
0.2 |
209 |
0.6 |
138 |
8 |
1.11 |
28 |
1.65 |
| DM-22PM180012312.5-19K |
12 |
0.05 |
312.5 |
0.15 |
244.2 |
2.3 |
0.59 |
10.7 |
0.51 |
| DM-22PM18001216.4-369K |
12 |
0.05 |
16.4 |
0.16 |
12.6 |
2.49 |
0.32 |
10.9 |
0.54 |
| DM-22PM180024140-64K |
24 |
0.1 |
140 |
0.169 |
103.2 |
1.352 |
1.461 |
6.121 |
0.607 |
The motor parameters are for reference only,please refer to real measured data;
We can customize parameters according to customer requirements.
Gear Motor Output Speed=DC Motor Speed/Gear Ratio ( n=nm/i)
Gear Motor Output Torque=DC Motor Torque*Gear Ratio*Gearbox Efficiency. ( t=tm*i*η) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
